BorgWarner S500SX Turbo Charger- (120/110) #179188

SHM-BWS500SX-88
BorgWarner S500SX Turbo Charger- (120/110) #179188
Please Call for Availability
1-800-290-3920
Availability: Current ETA from manufacturer: 40-50 business days

Description

This BorgWarner S500SX Turbo has an A/R of 0.85, T4 inlet flange, twin scroll housing, 88 mm compressor inducer, 99 mm exducer, and an 110 mm turbine wheel. This is a complete turbo, ready to bolt on to any application with a horsepower range of 900-1475 HP.

S400SX4 Turbocharger

  • 88mm/3.47'' Compressor Inducer Dia.
  • 120mm/4.73'' Compressor Wheel O.D.
  • 99mm/3.90'' Turbine Exducer Dia.
  • 110mm/4.32'' Turbine Wheel O.D.
  • 0.85 Turbine A/R
  • T4 Twin Flow Turbine Inlet
    Straight Compressor Outlet
  • BorgWarner #179188

Details

  • SHM-BWS500SX-88
  • SHM-BWS500SX-88
  • BorgWarner
  • Current ETA from manufacturer: 40-50 business days
  • New

Categories

Shipping Information

  • Item Requires Shipping
  • 75.0 lbs.
  • W16.0000” x H16.0000” x L16.0000”
  • Free GROUND Shipping
  • This item ships in its own box.
